Specifying the Asset Strip Orientation
This command syntax specifies the orientation of the asset strips connected to the PRO3X device. Usually you do not need to
perform this command unless your asset strips do NOT come with the tilt sensor, causing the PRO3X unable to detect the
asset strips' orientation.
config:# assetStrip <n> assetStripOrientation <orientation>
Variables:
<n> is the number of the FEATURE port where the selected asset strip is physically connected. For the PRO3X device with only
one FEATURE port, the number is always 1.
<orientation> is one of the options: topConnector or bottomConnector.
Orientation
topConnector
bottomConnector
Setting LED Colors for Connected Tags
This command syntax sets the LED color for all rack units on the asset strip #1 to indicate the presence of a connected asset
tag.
config:# assetStrip <n> LEDColorForConnectedTags <color>
Variables:
<color> is the hexadecimal RGB value of a color in HTML format. The <color> variable ranges from #000000 to #FFFFFF.
Setting LED Colors for Disconnected Tags
This command syntax sets the LED color for all rack units on the connected asset strip(s) to indicate the absence of a
connected asset tag.
config:# assetStrip <n> LEDColorForDisconnectedTags <color>
Variables:
<color> is the hexadecimal RGB value of a color in HTML format. The <color> variable ranges from #000000 to #FFFFFF.
Description
This option indicates that the asset strip is
mounted with the RJ-45 connector located on the
top.
This option indicates that the asset strip is
mounted with the RJ-45 connector located at the
bottom.
