Rack Unit Configuration

A rack unit refers to a tag port on the asset strips. A rack unit configuration command begins with rackUnit.
Naming a Rack Unit
This command syntax assigns or changes the name of the specified rack unit on the specified asset strip.
config:# rackUnit <n> <rack_unit> name "<name>"
Variables:
<n> is the number of the FEATURE port where the selected asset strip is physically connected. For the PRO3X device with only
one FEATURE port, the number is always 1.
<rack_unit> is the index number of the desired rack unit. The index number is available on the asset strip or the Asset Strip
page of the web interface.
<name> is a string comprising up to 64 ASCII printable characters. The <name> variable must be enclosed in quotes when it
contains spaces.
Setting the LED Operation Mode
This command syntax determines whether a specific rack unit on the specified asset strip follows the global LED color
settings.
config:# rackUnit <n> <rack_unit> LEDOperationMode <mode>
Variables:
<n> is the number of the FEATURE port where the selected asset strip is physically connected. For the PRO3X device with only
one FEATURE port, the number is always 1.
<rack_unit> is the index number of the desired rack unit. The index number is available on the asset strip or the Asset Strip
page of the web interface.
<mode> is one of the LED modes: automatic or manual.
Mode Description
automatic This option makes the LED of the specified rack unit
follow the global LED color settings.
This is the default.
