Setting the X Coordinate

This command specifies the X coordinate of an environmental sensor.
config:# externalsensor <n> xlabel "<coordinate>"
Variables:
<n> is the ID number of the environmental sensor that you want to configure. The ID number is available in the PRO3X web
interface or using the command "show externalsensors <n>" in the CLI. It is an integer starting at 1.
<coordinate> is a string comprising up to 24 ASCII printable characters, and it must be enclosed in quotes.

Setting the Y Coordinate

This command specifies the Y coordinate of an environmental sensor.
config:# externalsensor <n> ylabel "<coordinate>"
Variables:
<n> is the ID number of the environmental sensor that you want to configure. The ID number is available in the PRO3X web
interface or using the command "show externalsensors <n>" in the CLI. It is an integer starting at 1.
<coordinate> is a string comprising up to 24 ASCII printable characters, and it must be enclosed in quotes.

Setting the Z Coordinate

This command specifies the Z coordinate of an environmental sensor.
config:# externalsensor <n> zlabel "<coordinate>"
Variables:
<n> is the ID number of the environmental sensor that you want to configure. The ID number is available in the PRO3X web
interface or using the command "show externalsensors <n>" in the CLI. It is an integer starting at 1.
Depending on the Z coordinate format you set, there are two types of values for the <coordinate> variable:
Type Description
Free form <coordinate> is a string comprising up to 24 ASCII
printable characters, and it must be enclosed in
quotes.
Rack units <coordinate> is an integer number in rack units.
