Additional sensors supported by specific models:
Specific PRO3X models support some or all of the following sensors. The CLI command(s) listed above can be also applied to
the following sensors. Note that the measurement unit of current values in CLI is A, not mA.
Sensor type
peakCurrent
reactivePower
displacementPowerFactor
residualCurrent
residualDCCurrent
Inlet Pole Sensor Threshold Information
This command syntax shows the specified inlet pole sensor's threshold-related information.
# show sensor inletpole <n> <p> <sensor type>
To show detailed information, add the parameter "details" to the end of the command.
# show sensor inletpole <n> <p> <sensor type> details
Variables:
<n> is the number of the inlet whose pole sensors you want to query. For a single-inlet PDU, <n> is always 1.
<p> is the label of the inlet pole whose sensors you want to query.
Pole Label
<p>
1 L1
2 L2
3 L3
Description
Peak current sensor
Reactive power sensor
Displacement power factor sensor
RCM current sensor
▪ For Type A, it is the sensor that detects
residual AC current.
▪ For Type B, it is the sensor that detects both
residual AC and DC current.
RCM DC current sensor - detects residual DC
current only.
Available only on PDUs with RCM Type B.
Current sensor
L1
L2
L3
PRO3X User Guide – Command Line Interface (CLI)
24 of 182
Using the PRO3X Command Line Interface (CLI)
Voltage sensor
L1 - L2
L2 - L3
L3 - L1
