<hy_value> is a numeric value that is assigned to the hysteresis for the specified inlet pole sensor.
<as_value> is a number in samples that is assigned to the assertion timeout for the specified inlet pole sensor.
Additional sensors supported by specific models:
Specific PRO3X models support some or all of the following sensors. The CLI command(s) listed above can be also applied to
the following sensors. Note that the measurement unit of current values in CLI is A, not mA.
Sensor type
peakCurrent
reactivePower
displacementPowerFact
or
residualCurrent
residualDCCurrent
\

Commands for Overcurrent Protector Sensors

A sensor configuration command for overcurrent protectors begins with sensor ocp.
You can configure various overcurrent protector threshold settings at a time by combining multiple commands.
Set the Upper Critical threshold for an overcurrent protector:
sensor ocp <n> <sensor type> upperCritical <option>
Set the Upper Warning threshold for an overcurrent protector:
sensor ocp <n> <sensor type> upperWarning <option>
Set the Lower Critical threshold for an overcurrent protector:
sensor ocp <n> <sensor type> lowerCritical <option>
Description
Peak current sensor
Reactive power sensor
Displacement power factor sensor
RCM current sensor
▪ For Type A, it is the sensor that detects
residual AC current.
▪ For Type B, it is the sensor that detects
both residual AC and DC current.
RCM DC current sensor - detects residual DC
current only.
Available only on PDUs with RCM Type B.
