5.1.3

Display of the Process Value

The flow rate (PV), flow velocity, volumetric flow rate, mass flow rate, totalized value, calorie,
flow noise, electrode adhesion, electrode potential, and conductivity can be checked with the
following parameters. However, calorie, flow noise and conductivity are parameters which can be
checked only with AXG, and they are hidden with AXW.
Flow rate (PV), flow velocity, volumetric flow rate, mass flow rate,
„ „
totalized value, calorie
Menu path
Display
F
OUNDATION
Fieldbus
Block Relative
Name Index
- -
- -
STB 37
STB 29
STB 33
STB 41
STB 47
STB 49
Device setup ► Process variables ► (see below)
Process Variables ► STB ► Process Variables ► Dynamic Variables ► Device Variables
► (see below)
Parameter
Display
Flow rate(%) -
Flow rate -
Velocity Value ► Velocity
-
Value.Status
Velocity Value ► Velocity
Velocity
Value.Value
Volume Flow Value ► Volume
-
Flow Value.Status
Volume Flow Value ► Volume
Volume
Flow Value.Value
Mass Flow Value ► Mass Flow
-
Value.Status
Mass Flow Value ► Mass Flow
Mass
Value.Value
Calorific Value ► Calorific
-
Value.Status
Calorific Value ► Calorific
Calorie
Value.Value
Total 1 Value ► Total 1 Value.
-
Status
Total 1 Value ► Total 1 Value.
Totalizer ►Totalizer 1
Value
Total 2 Value ► Total 2 Value.
-
Status
Total 2 Value ► Total 2 Value.
Totalizer ►Totalizer 2
Value
<5. Functions>
F Fieldbus
OUNDATION
Description
Displays the percentage to the
range for the process value set
to the Primary Value.
Displays the process value set
to the Primary Value.
Displays the status of the flow
velocity.
Displays the value of the flow
velocity.
Displays the status of
volumetric flow rate.
Displays the value of the
volumetric flow rate.
Displays the status of the mass
flow rate.
Displays the value of the mass
flow rate.
Displays the status of calorie
(only available for AXG, not for
AXW).
Displays the value of calorie
(only available for AXG, not for
AXW).
Displays the status of totalizer
1.
Displays the value of totalizer 1.
Displays the status of totalizer
2.
Displays the value of totalizer 2.
