3.16. Main Menu - Data Readouts - Group 16

3.16.1. 16-** Data Readouts
Parameter group for data read-outs, e.g. actual references, voltages, control, alarm, warning and status words.
3.16.2. 16-0* General Status
Parameters for reading the general status, e.g. the calculated reference, the active control word, status.
16-00 Control Word
Range:
*
0 [0 - FFFF]
16-01 Reference [Unit]
Range:
*
[-999999.000 - 999999.000] View the present reference value applied on impulse or analog basis in the unit resulting from the configuration
0.000
16-02 Reference %
Range:
*
0% [-200 to 200 %]
16-03 Status Word
Range:
*
0 [0 - FFFF]
16-05 Main Actual Value [%]
Range:
*
0% [-100 to +100%]
16-09 Custom Readout
Range:
*
0 [-999999.99 to 999999.99]
3.16.3. 16-1* Motor Status
Parameters for reading the motor status values.
16-10 Power [kW]
Range:
*
0.0kW [0.0 - 1000.0 kW]
Function:
View the Control word sent from the frequency converter via the serial communication port in hex code.
Function:
selected in par. 1-00 (Hz, Nm or RPM).
Function:
View the total reference. The total reference is the sum of digital, analog, preset, bus, and freeze references,
plus catch-up and slow-down.
Function:
View the Status word sent from the frequency converter via the serial communication port in hex code.
Function:
View the two-byte word sent with the Status word to the bus Master reporting the Main Actual Value.
Function:
View the user-defined readouts as defined in par. 0-30, 0-31 and 0-32.
Function:
View the motor power in kW. The value shown is calculated on the basis of the actual motor voltage and motor
current. The value is filtered, and therefore approx. 30 ms may pass from when an input value changes to when
the data read-out values change.
