[1660] Digital Input
[1662] Analog Input 53
[1664] Analog Input 54
[1665] Analog Output 42 [mA]
[1666] Digital Output [bin]
[1675] Analog In X30/11
[1676] Analog In X30/12
[1677] Analog Out X30/8 [mA]
[1690] Alarm Word
[1691] Alarm Word 2
[1692] Warning Word
[1693] Warning Word 2
[1694] Ext. Status Word
[1695] Ext. Status Word 2
[1820] Analog Input X42/1
[1821] Analog Input X42/3
[1822] Analog Input X42/5
[1823] Analog Out X42/7 [mA]
[1824] Analog Out X42/9 [mA]
[1825] Analog Out
[mA]
15-11 Logging Interval
Range:
*
1ms [1 - 86400000 ms]
15-12 Trigger Event
Option:
* False
[0]
[1] True
[2] Running
[3] In range
[4] On reference
[5] Torque limit
[6] Current limit
[7] Out of current range
[8] Below I low
[9] Above I high
[10] Out of speed range
[11] Below speed low
[12] Above speed high
[13] Out of feedb. range
[14] Below feedb. low
[15] Above feedb. high
X42/11 Select which variables are to be logged.
Function:
Enter the interval in milliseconds between each sampling of the variables to be logged.
Function:
Selects the trigger event. When the trigger event occurs, a window is applied to freeze the log. The log will then
retain a specified percentage of samples before the occurrence of the trigger event (par. 15-14).
