Parameters

4.13 Main Menu - Data Readouts 2 - Group

18
Parameters in this group are array parameters, where up to
10 fault logs can be viewed. [0] is the most recent logged
data, and [9] the oldest. Error codes, values, and time
stamp can be viewed for all logged data
4.13.1 18-1* Fire Mode Log
18-10 FireMode Log:Event
Range: Function:
0 [0 - 255 ] View Firemode event.
*
4.13.2 18-5* Ref. & Feedb.
18-50 Sensorless Readout [unit]
View the pressure or flow resulting from the sensorless
calculations. This value is not the value used for control. The
value will only be updated if sensorless data supports both flow
and pressure.
Range:
0 SensorlessUnit [-999999.999 -
*
999999.999
SensorlessUnit]

4.14 Main Menu - FC Closed Loop - Group

20
This parameter group is used for configuring the closed
loop PI Controller, that controls the output frequency of
the frequency converter.
4.14.1 20-0* Feedback
This parameter group is used to configure the feedback
signal for the closed loop PI control of the frequency
converter.
20-00 Feedback 1 Source
Option: Function:
This parameter defines the inputs
used as the source of the feedback
signal.
[0] No function
[1] Analog Input 53
[2] Analog Input 54
[3] Pulse input 29
[100] Bus Feedback 1
[104] Sensorless Flow
[105] Sensorless Pressure
®
VLT DriveMotor FCP 106 and FCM 106 Programming Guide
20-01 Feedback 1 Conversion
Option:
[0] Linear
*
[1] Square
root
20-12 Reference/Feedback Unit
4.14.2 20-6* Sensorless
20-60 Sensorless Unit
Select the unit to be used with 18-50 Sensorless Readout.
Option:
[20]
20-69 Sensorless Information
Range:
Function:
0
*
4.14.3 20-8* PI Basic Settings
Parameters for configuring the Process PI control.
20-81 PI Normal/ Inverse Control
Option:
[0] Normal Causes the frequency converter's output frequency
*
[1] Inverse Causes the frequency converter's output frequency
20-83 PI Start Speed [Hz]
Range:
0 Hz
*
MG03N102 - Rev. 2013-12-02
Function:
This parameter allows a conversion function to
be applied to Feedback 1.
[0] Linear has no effect on the feedback.
[1] Square root is commonly used when a
pressure sensor is used to provide flow
feedback
( ).
flow ∝ pressure
l/s
Function:
[0 - 0 ] View information about the sensorless data.
Function:
to decrease when the feedback is greater than the
setpoint reference. This is common for pressure-
controlled supply fan and pump applications.
to increase when the feedback is greater than the
setpoint reference. This is common for
temperature-controlled cooling applications, such
as cooling towers.
Function:
[ 0 - Enter the motor speed to be attained as a
200.0 Hz] start signal for commencement of PI control.
Upon power up, the frequency converter
operates using speed open loop control.
When the Process PI start speed is reached,
the frequency converter changes to PI control.
4
Function:
85
4
