NB!
This parameter is active only when par. 8-30
3.9.8. 8-8* FC Port Diagnostics
These parameters are used for monitoring the Bus communication via the FC Port.
8-80 Bus Message Count
Option:
8-81 Bus Error Count
Option:
8-82 Slave Message Count
Option:
8-83 Slave Error Count
Option:
3.9.9. 8-9* Bus Jog
Parameters for configuring the Bus Jog.
8-90 Bus Jog 1 Speed
Range:
*
100 RPM [0 - par. 4-13 RPM]
8-91 Bus Jog 2 Speed
Range:
*
200 RPM [0 - par. 4-13 RPM]
8-94 Bus Feedback 1
Range:
*
0 [-200 - 200]
8-95 Bus Feedback 2
Range:
*
0 [-200 - 200]
8-96 Bus Feedback 3
Range:
*
0 [-200 - 200]
Protocol
is set to [9]
Function:
This parameter shows the number of valid telegrams detected on the bus.
Function:
This parameter shows the number of telegrams with faults (e.g. CRC fault), detected on the bus.
Function:
This parameter shows the number of valid telegrams adressed to the slave, sent by the frequency converter.
Function:
This parameter shows the number of error telegrams, which could not be executed by the frequency converter.
Function:
Enter the jog speed. This is a fixed jog speed activated via the serial port or fieldbus option.
Function:
Enter the jog speed. This is a fixed jog speed activated via the serial port or fieldbus option.
Function:
Write a feedback to this parameter via the serial communication port or fieldbus option. This parameter must be
selected in par. 20-00, 20-03 or 20-06 as a feedback source.
Function:
Bus Feedback 1
See par. 8-94 for further details.
Function:
Bus Feedback 1
See par. 8-94 for further details.
