3. Parameter Description
[4] On reference
[5] Torque limit
[6] Current limit
[7] Out of current range
[8] Below I
[9] Above I
[10] Out of speed range
3
[11] Below speed low
[12] Above speed high
[13] Out of feedb. range
[14] Below feedb. low
[15] Above feedb. high
[16] Thermal warning
[17] Mains out of range
[18] Reversing
[19] Warning
[20] Alarm (trip)
[21] Alarm (trip lock)
[22] Comparator 0
[23] Comparator 1
[24] Comparator 2
[25] Comparator 3
[26] Logic rule 0
[27] Logic rule 1
[28] Logic rule 2
[29] Logic rule 3
[33] Digital input DI18
[34] Digital input DI19
[35] Digital input DI27
[36] Digital input DI29
[37] Digital input DI32
[38] Digital input DI33
[39] Start command
[40] Drive Stopped
[41] Reset Trip
[42] Auto Reset Trip
[43] OK Key
[44] Reset
[45] Left Key
[46] Right Key
[47] Up Key
[48] Down Key
[50] Comparator 4
[51] Comparator 5
[60] Logic Rule 4
[61] Logic Rule 5
116
See parameter group 5-3* for further description.
See parameter group 5-3* for further description.
See parameter group 5-3* for further description.
See parameter group 5-3* for further description.
See parameter group 5-3* for further description.
LOW
See parameter group 5-3* for further description.
HIGH
See parameter group 5-3* for further description.
See parameter group 5-3* for further description.
See parameter group 5-3* for further description.
See parameter group 5-3* for further description.
See parameter group 5-3* for further description.
See parameter group 5-3* for further description.
See parameter group 5-3* for further description.
See parameter group 5-3* for further description.
Use the result of comparator 0 in the logic rule.
Use the result of comparator 1 in the logic rule.
Use the result of comparator 2 in the logic rule.
Use the result of comparator 3 in the logic rule.
Use the result of logic rule 0 in the logic rule.
Use the result of logic rule 1 in the logic rule.
Use the result of logic rule 2 in the logic rule.
Use the result of logic rule 3 in the logic rule.
Use the value of DI18 in the logic rule (High = TRUE).
Use the value of DI19 in the logic rule (High = TRUE).
Use the value of DI27 in the logic rule (High = TRUE).
Use the value of DI29 in the logic rule (High = TRUE).
Use the value of DI32 in the logic rule (High = TRUE).
Use the value of DI33 in the logic rule (High = TRUE).
This event is TRUE if the frequency converter is started by any means (either via digital input, field bus or other).
This event is TRUE if the frequency converter is stopped or coasted by any means (either via digital input,
fieldbus or other).
This event is TRUE if the frequency converter is tripped (but not trip-locked) and the reset button is pressed.
This event is TRUE if the frequency converter is tripped (but not trip-locked) and an Automatic Reset is issued.
This event is TRUE if the OK key on the LCP is pressed.
This event is TRUE if the Reset key on the LCP is pressed.
This event is TRUE if the Left key on the LCP is pressed.
This event is TRUE if the Right key on the LCP is pressed.
This event is TRUE if the Up key on the LCP is pressed.
This event is TRUE if the Down key on the LCP is pressed.
Use the result of comparator 4 in the logic rule.
Use the result of comparator 5 in the logic rule.
Use the result of logic rule 4 in the logic rule.
Use the result of logic rule 5 in the logic rule.
