VLT HVAC Drive Programming Guide
[41] Reset Trip
[42] Auto Reset Trip
[43] OK Key
[44] Reset Key
[45] Left Key
[46] Right Key
[47] Up Key
[48] Down Key
[50] Comparator 4
[51] Comparator 5
[60] Logic rule 4
[61] Logic rule 5
[70] SL Time-out 3
[71] SL Time-out 4
[72] SL Time-out 5
[73] SL Time-out 6
[74] SL Time-out 7
13-41 Logic Rule Operator 1
Array [6]
* DISABLED
[0]
[1] AND
[2] OR
[3] AND NOT
[4] OR NOT
[5] NOT AND
[6] Not or
[7] Not and not
[8] Not or not
13-42 Logic Rule Boolean 2
Array [6]
13-43 Logic Rule Operator 2
Array [6]
* DISABLED
[0]
This logic rule is TRUE if the frequency converter is tripped (but not trip-locked) and the reset button is pressed.
This logic rule is TRUE if the frequency converter is tripped (but not trip-locked) and an Automatic Reset is
issued.
This logic rule is TRUE if the OK key on the LCP is pressed.
This logic rule is TRUE if the Reset key on the LCP is pressed.
This logic rule is TRUE if the Left key on the LCP is pressed.
This logic rule is TRUE if the Right key on the LCP is pressed.
This logic rule is TRUE if the Up key on the LCP is pressed.
This logic rule is TRUE if the Down key on the LCP is pressed.
Use the result of comparator 4 in the logic rule.
Use the result of comparator 5 in the logic rule.
Use the result of logic rule 4 in the logic rule.
Use the result of logic rule 5 in the logic rule.
Use the result of timer 3 in the logic rule.
Use the result of timer 4 in the logic rule.
Use the result of timer 5 in the logic rule.
Use the result of timer 6 in the logic rule.
Use the result of timer 7 in the logic rule.
Select the first logical operator to use on the Boolean inputs from par. 13-40 and 13-42.
[13 -XX] signifies the boolean input of par. 13-*.
Ignores par. 13-42, 13-43, and 13-44.
evaluates the expression [13-40] AND [13-42].
evaluates the expression [13-40] OR [13-42].
evaluates the expression [13-40] AND NOT [13-42].
evaluates the expression [13-40] OR NOT [13-42].
evaluates the expression NOT [13-40] AND [13-42].
evaluates the expression NOT [13-40] OR [13-42].
evaluates the expression NOT [13-40] AND NOT [13-42].
evaluates the expression NOT [13-40] OR NOT [13-42].
Select the second boolean (TRUE or FALSE) input for the selected logic rule.
See Parameter 13-40 for further descriptions of choices and their functions.
Select the second logical operator to be used on the boolean input calculated in par. 13-40, 13-41, and 13-42,
and the boolean input coming from par. 13-42.
[13-44] signifies the boolean input of par. 13-44.
[13-40/13-42] signifies the boolean input calculated in par. 13-40, 13-41, and 13-42. DISABLED [0] (factory
setting). select this option to ignore par. 13-44.
