3. Parameter Description
6-60 Terminal X30/8 Output
Option:
*
No operation
[0]
[100] Output frequency
[101] Reference
[102] Feedback
3
[103] Motor Current
[104] Torque re. to lim.
[105] Torque rel. to rated
[106] Power
[107] Speed
[108] Torque
[109] Max Out Freq
[113] Ext. Closed Loop 1
[114] Ext. Closed Loop 2
[115] Ext. Closed Loop 3
[130] Output freq. 4-20 mA
[131] Reference 4-20 mA
[132] Feedback 4-20 mA
[133] Motor cur. 4-20 mA
[134] Torq. % lim 4-20 mA
[135] Torq. % nom 4-20 mA
[136] Power 4-20 mA
[137] Speed 4-20 mA
[138] Torque 4-20 mA
[139] Bus Ctrl 0-20 mA
[140] Bus Ctrl 4-20 mA
[141] Bus Ctrl timeout 0-20
mA
[142] Bus Ctrl timeout 4-20
mA
[143] Ext. Closed Loop 1 4-20
mA
[144] Ext. Closed Loop 2 4-20
mA
[145] Ext. Closed Loop 3 4-20
mA
6-61 Term. X30/8 Output Min Scale
Range:
*
0% [0.00 - 200 %]
6-62 Term. X30/8 Output Max Scale
Range:
*
100% [0.00 - 200 %]
88
Function:
Function:
Scales the minimum output of the selected analog signal on terminal X30/8. Scale the minimum value as a
percentage of the maximum signal value, i.e. 0 mA (or 0 Hz) is desired at 25% of the maximum output value
and 25% is programmed. The value can never be higher than the corresponding setting in par. 6-62 if value is
below 100%.
This parameter is active when option module MCB 101 is mounted in the frequency converter.
Function:
Scales the maximum output of the selected analog signal on terminal X30/8. Scale the value to the desired
maximum value of the current signal output. Scale the output to give a lower current than 20 mA at full scale or
