VLT HVAC Drive Programming Guide
[8-90 ] Bus Jog 1 Speed
[8-91 ] Bus Jog 2 Speed
[16-80] Fieldbus CTW 1 (Fixed)
[16-82 ] Fieldbus REF 1 (Fixed)
10-12 Process Data Config Read
Option:
None
[16-00 ] Control Word
[16-01 ] Reference [Unit]
[16-02 ] Reference %
[16-03 ] Status Word (Fixed)
[16-05 ] Main Actual Value (%)
(Fixed)
[16-10 ] Power [kW]
[16-11 ] Power [hp]
[16-12 ] Motor Voltage
[16-13 ] Frequency
[16-14 ] Motor Current
[16-15 ] Frequency [%]
[16-16 ] Torque
[16-17 ] Speed [RPM]
[16-18 ] Motor Thermal
[16-22 ] Torque [%]
[16-30 ] DC Link Voltage
[16-32 ] BrakeEnergy/s
[16-33 ] BrakeEnergy/2 min
[16-34 ] Heatsink Temp.
[16-35 ] Inverter Thermal
[16-38 ] SL Control State
[16-39] Controlcard Temp.
[16-50 ] External Reference
[16-52 ] Feedback [Unit]
[16-53 ] Digi Pot Reference
[16-54] Feedback 1 [Unit]
[16-55 ] Feedback 2 [Unit]
[16-56 ] Feedback 3 [Unit]
[16-60 ] Digital Input
[16-61 ] Terminal 53
Setting
[16-62 ] Analog Input 53
[16-63 ] Terminal 54
Setting
[16-64 ] Analog Input 54
[16-65 ] Analog Output 42 [mA]
Function:
Select the process read data for I/O Assembly Instances 101/151. Elements [2] and [3] of this array can be
selected. Elements [0] and [1] of the array are fixed.
Switch
Switch
