3. Parameter Description
3.8.6. 6-4* Analog Input 4 (MCB 101)
Parameter group for configuring the scale and limits for analog input 4 (X30/12) placed on option module MCB 101.
6-40 Term. X30/12 Low Voltage
Range:
*
0.7 V
[0 to par. 6-41]
3
6-41 Term. X30/12 High Voltage
Range:
*
10.0V
[Par. 6-40 to 10.0 V]
6-44 Term. X30/12 Low Ref./Feedb. Value
Range:
*
0.000 Unit
[-1000000.000 to par.
6-45]
6-45 Term. X30/12 High Ref./Feedb. Value
Range:
*
1500.000 Unit
[Par. 6-44 to
1000000.000]
6-46 Term. X30/12 Filter Time Constant
Range:
*
0.001s
[0.001 - 10.000 s]
6-47 Term. X30/12 Live Zero
Option:
*
Disabled
[0]
[1]
Enabled
3.8.7. 6-5* Analog Output 1
Parameters for configuring the scaling and limits for analog output 1, i.e. Terminal 42. Analog outputs are current outputs: 0/4 – 20 mA. Common terminal
(terminal 39) is the same terminal and has the same electrical potential for analog common and digital common connection. Resolution on analog output
is 12 bit.
6-50 Terminal 42 Output
Option:
[0]
No operation
*
Output frequency
[100]
[101]
Reference
[102]
Feedback
[103]
Motor current
84
Function:
Sets the analog input scaling value to correspond to the low reference/feedback value set in par. 6-44.
Function:
Sets the analog input scaling value to correspond to the high reference/feedback value set in par. 6-45.
Function:
Sets the analog input scaling value to correspond to the low voltage value set in par. 6-40.
Function:
Sets the analog input scaling value to correspond to the high voltage value set in par. 6-41.
Function:
A 1
st
order digital low pass filter time constant for suppressing electrical noise on terminal X30/12.
Par. 6-46 cannot be changed while the motor is running.
Function:
This parameter makes it possible to disable the Live Zero monitoring. E.g. to be used if the analog outputs are
used as part of a decentral I/O system (e.g. when not part of any frequency converter related control functions,
but feeding a Building Management System with data)
Function:
Select the function of Terminal 42 as an analog current output.
: 0 - 100 Hz
: Minimum reference - Maximum reference
: -200% to +200% of par. 2-14
: 0 - Inverter Max. Current (par. 16-37)
MG.11.C5.02 - VLT
®
is a registered Danfoss trademark
®
VLT
HVAC Drive Programming Guide
