3. Parameter Description
[1684] Comm. Option STW
[1685] FC Port CTW 1
[1686] FC Port REF 1
[1690] Alarm Word
[1691] Alarm Word 2
[1692] Warning Word
[1693] Warning Word 2
3
[1694] Ext. Status Word
[1695] Ext. Status Word 2
[1696] Maintenance Word
[1830] Analog Input X42/1
[1831] Analog Input X42/3
[1832] Analog Input X42/5
[1833] Analog Out X42/7 [V]
[1834] Analog Out X42/9 [V]
[1835] Analog Out X42/11 [V] Shows the value of the signal applied to terminal X42/11 on the Analog I/O card.
[2117] Ext. 1 Reference [Unit] The value of the reference for extended Closed Loop Controller 1
[2118] Ext. 1 Feedback [Unit]
[2119] Ext. 1 Output [%]
[2137] Ext. 2 Reference [Unit] The value of the reference for extended Closed Loop Controller 2
[2138] Ext. 2 Feedback [Unit]
[2139] Ext. 2 Output [%]
[2157] Ext. 3 Reference [Unit] The value of the reference for extended Closed Loop Controller 3
[2158] Ext. 3 Feedback [Unit]
[2159] Ext. 3 Output [%]
[2230] No-Flow Power
[2580] Cascade Status
[2581] Pump Status
NB!
Please consult the
0-21 Display Line 1.2 Small
Option:
*
Motor Current [A]
[1614]
0-22 Display Line 1.3 Small
Option:
* Power [kW]
[1610]
30
Extended fieldbus communication option status word.
Control word (CTW) received from the Bus Master.
Status word (STW) sent to the Bus Master.
One or more alarms in a Hex code (used for serial communications)
One or more alarms in a Hex code (used for serial communications)
One or more warnings in a Hex code (used for serial communications)
One or more warnings in a Hex code (used for serial communications)
One or more status conditions in a Hex code (used for serial communications)
One or more status conditions in a Hex code (used for serial communications)
The bits reflect the status for the programmed Preventive Maintenance Events in parameter group 23-1*
Shows the value of the signal applied to terminal X42/1 on the Analog I/O card.
Shows the value of the signal applied to terminal X42/3 on the Analog I/O card.
Shows the value of the signal applied to terminal X42/5 on the Analog I/O card.
Shows the value of the signal applied to terminal X42/7 on the Analog I/O card.
Shows the value of the signal applied to terminal X42/9 on the Analog I/O card.
The value of the feedback signal for extended Closed Loop Controller 1
The value of the output from extended Closed Loop Controller 1
The value of the feedback signal for extended Closed Loop Controller 2
The value of the output from extended Closed Loop Controller 2
The value of the feedback signal for extended Closed Loop Controller 3
The value of the output from extended Closed Loop Controller 3
The calculated No Flow Power for the actual operating speed
Status for the operation of the Cascade Controller
Status for the operation of each individual pump controlled by the Cascade Controller
VLT HVAC Drive Programming Guide, MG.11.Cx.yy
Function:
Select a variable for display in line 1, middle position.
The options are the same as those listed for par. 0-20
Function:
Select a variable for display in line 1, right position.
The options are the same as those listed for par. 0-20
MG.11.C5.02 - VLT
®
VLT
for detailed information.
Display Line 1.1 Small
Display Line 1.1 Small
