VLT HVAC Drive Programming Guide
[17] Select preset reference
7
[18] Select ramp 1
[19] Select ramp 2
[22] Run
[23] Run reverse
[24] Stop
[26] Dcstop
[27] Coast
[28] Freeze output
[29] Start timer 0
[30] Start timer 1
[31] Start timer 2
[32] Set digital output A low Any output with 'digital output 1' selected is low (off).
[33] Set digital output B low Any output with 'digital output 2' selected is low (off).
[34] Set digital output C low Any output with 'digital output 3' selected is low (off).
[35] Set digital output D low Any output with 'digital output 4' selected is low (off).
[36] Set digital output E low Any output with 'digital output 5' selected is low (off).
[37] Set digital output F low Any output with 'digital output 6' selected is low (off).
[38] Set digital output A
high
[39] Set digital output B
high
[40] Set digital output C
high
[41] Set digital output D
high
[42] Set digital output E
high
[43] Set digital output F
high
[60] Reset Counter A
[61] Reset Counter B
[70] Start Timer 3
[71] Start Timer 4
[72] Start Timer 5
[73] Start Timer 6
[74] Start Timer 7
Selects preset reference 7. If the active preset reference is changed, it will merge with other preset reference
commands coming from either the digital inputs or via a fieldbus.
Selects ramp 1
Selects ramp 2
issues a start command to the frequency converter.
Issues a start reverse command to the frequency converter.
Issues a stop command to the frequency converter.
Issues a DC stop command to the frequency converter.
The frequency converter coasts immediately. All stop commands including the coast command stop the SLC.
Freezes the output frequency of the frequency converter.
Starts timer 0, see par. 13-20 for further description.
Starts timer 1, see par. 13-20 for further description.
Starts timer 2, see par. 13-20 for further description.
Any output with 'digital output 1' selected is high (closed).
Any output with 'digital output 2' selected is high (closed).
Any output with 'digital output 3' selected is high (closed).
Any output with 'digital output 4' selected is high (closed).
Any output with 'digital output 5' selected is high (closed).
Any output with 'digital output 6' selected is high (closed).
Resets Counter A to zero.
Resets Counter A to zero.
Starts timer 3, see par. 13-20 for further description.
Starts timer 4, see par. 13-20 for further description.
Starts timer 5, see par. 13-20 for further description.
Starts timer 6, see par. 13-20 for further description.
Starts timer 7, see par. 13-20 for further description.
