VLT HVAC Drive Programming Guide
[0] Disable
* Enable cyclic master
[1]
9-53 Profibus Warning Word
Option:
Read only
Bit: Meaning:
0 Connection with DP-master is not ok
1 Not used
2 FDL (Field-bus Data link Layer) is not ok
3 Clear data command received
4 Actual value is not updated
5 Baudrate search
6 PROFIBUS ASIC is not transmitting
7 Initializing of PROFIBUS is not ok
8 Frequency converter is tripped
9 Internal CAN error
10 Wrong configuration data from PLC
11 Wrong ID sent by PLC
12 Internal error occured
13 Not configured
14 Timeout active
15 Warning 34 active
9-63 Actual Baud Rate
Option:
Read only
[0] 9.6 kbit/s
[1] 19.2 kbit/s
[2] 93.75 kbit/s
[3] 187.5 kbit/s
[4] 500 kbit/s
[6] 1500 kbit/s
[7] 3000 kbit/s
[8] 6000 kbit/s
[9] 12000 kbit/s
[10] 31.25 kbit/s
[11] 45.45 kbit/s
[255] No baud rate found
9-65 Profile Number
Range:
Read only
*
0 [0 - 0]
NB!
This parameter is not visible via LCP.
Disables process control via Profibus, and enables process control via standard fieldbus or Profibus Master class
2.
Enables process control via Profibus Master Class 1, and disables process control via standard fieldbus or Profibus
Master class 2.
Function:
This parameter displays Profibus communication warnings. Please refer to the
for further information.
Function:
This parameter displays the actual Profibus baud rate. The Profibus Master automatically sets the baud rate.
Function:
This parameter contains the profile identification. Byte 1 contains the profile number and byte 2 the version
number of the profile.
MG.11.C5.02 - VLT ® is a registered Danfoss trademark
3. Parameter Description
Profibus Operating Instructions
103
3
