VLT HVAC Drive Programming Guide
The Quick Setup menu gives access to the 13 most important setup parameters of the frequency converter. After programming the frequency converter
will, in most cases be ready for operation. The 13 (see footnote) Quick Setup parameters are shown in the table below. A complete description of the
function is given in the parameter description sections of this manual.
Par. Designation
0-01 Language
1-20 Motor Power
1-21 Motor Power*
1-22 Motor Voltage
1-23 Motor Frequency
1-24 Motor Current
1-25 Motor Nominal Speed
1-28 Motor Rotation Check
3-41 Ramp 1 Ramp up Time
3-42 Ramp 1 Ramp down Time
4-11 Motor Speed Low Limit
4-12 Motor Speed Low Limit*
4-13 Motor Speed High Limit
4-14 Motor Speed High Limit*
3-19 Jog Speed
3-11 Jog Speed*
5-12 Terminal 27 Digital Input
5-40 Function Relay **
Table 2.1: Quick Setup parameters
*The display showing depends on choices made in parameter 0-02 and 0-03. The default settings of parameters 0-02 and 0-03 depend on which region
of the world the frequency converter is supplied to but can be re-programmed as required.
Function Relay,
** Par. 5-40 is an array, where one may choose between Relay1 [0] or Relay2 [1]. Standard setting is Relay1 [0] with the default choice
Alarm [9].
See the parameter description later in this chapter under Function Setup parameters.
For a detailed information about settings and programming, please see the
Guide, MG.11.JX.YY
x=version number
y=language
VLT HVAC Drive Programming Guide, MG.11.CX.YY
MG.11.C5.02 - VLT ® is a registered Danfoss trademark
2. How to Programme
[Units]
[kW]
[HP]
[V]
[Hz]
[A]
[RPM]
[Hz]
[s]
[s]
[RPM]
[Hz]
[RPM]
[Hz]
[RPM]
[Hz]
or ADS 102 Programming
