3. Parameter Description
NB!
To achieve the highest accuracy with the slip compensation, an Automatic Motor Adaptation (AMA) should be performed. To be enabled
in parameter 1-29.
NB!
Trip will not be active when using a normal stop- or coast command.
3
1-86 Trip Speed [RPM]
Range:
*
0 [0 to Motor Speed High limit (par.
4-13)]
NB!
This parameter is only available if
1-87 Trip Speed [Hz]
Range:
*
0 [0 to Motor Speed High limit (par.
4-14)]
NB!
This parameter is only available if
3.3.9. 1-9* Motor Temperature
Parameters for setting the temperature protection features for the motor.
1-90 Motor Thermal Protection
Option:
[0] No protection
[1] Thermistor warning
[2] Thermistor trip
46
Function:
Set the desired motor speed for trip limit.
If the Trip Speed is set to 0, the function is not active.
par. 0-02 Motor Speed Unit
Function:
If the Trip Speed is set to 0, the function is not active.
par. 0-02 Motor Speed Unit
Function:
The frequency converter determines the motor temperature for motor protection in two different ways:
• Via a thermistor sensor connected to one of the analog or digital inputs (par. 1-93
Source
).
• Via calculation (ETR = Electronic Thermal Relay) of the thermal load, based on the actual load and
time. The calculated thermal load is compared with the rated motor current I
frequency f . The calculations estimate the need for a lower load at lower speed due to less cool-
M,N
ing from the fan incorporated in the motor.
If the motor is continuously overloaded and no warning or trip of frequency converter is wanted.
Activates a warning when the connected thermistor in the motor reacts in the event of motor over-temperature.
Stops (trips) the frequency converter when the connected thermistor in the motor reacts in the event of motor
over-temperature.
MG.11.C5.02 - VLT ® is a registered Danfoss trademark
®
VLT HVAC Drive Programming Guide
is set to [RPM].
Set the desired motor speed for trip limit.
is set to [Hz].
Thermistor
and the rated motor
M,N
