VLT HVAC Drive Programming Guide
8-06 Reset Control Timeout
Option:
* Do not reset
[0]
[1] Do reset
8-07 Diagnosis Trigger
Option:
* Disable
[0]
[1] Trigger on alarms
[2] Trigger alarms/warn.
3.9.3. 8-1* Ctrl. Word Settings
Parameters for configuring the option control word profile.
8-10 Control Profile
Option:
*
FC profile
[0]
8-13 Configurable Status Word STW
Option:
[0] No function
*
Profile default
[1]
[2] Alarm 68 only
[3] Trip except Alarm 68
[10] T18 DI status
[11] T19 DI status
[12] T27 DI status
[13] T29 DI status
[14] T33 DI status
[15] T33 DI status
[16] T37 DI status
[21] Thermal warning
[30] Brake fault (IGBT)
[40] Out of ref range
[60] Comparator 0
[61] Comparator 1
Function:
This parameter is active only when the choice
Function
.
Retains the set-up specified in par. 8-04, [Select setup 1-4] following a control time-out.
Returns the frequency converter to the original set-up following a control word time-out. When the value is set
Do reset
to [1], the frequency converter performs the reset and then immediately reverts to the
[0] setting.
Function:
This parameter has no function for LonWorks.
Function:
Select the interpretation of the control and status words corresponding to the installed fieldbus. Only the se-
lections valid for the fieldbus installed in slot A will be visible in the LCP display.
Function:
This parameter enables configuration of bit 12 – 15 in the status word.
Function corresponds to the profile default selected in par. 8-10.
Only set in case of an Alarm 68.
Set in case of a trip, except if the trip is executed by an Alarm 68.
The bit indicates the status of terminal 37.
"0" indicates T37 is low (safe stop)
"1" indicates T37 is high (normal)
MG.11.C5.02 - VLT ® is a registered Danfoss trademark
3. Parameter Description
Hold set-up
[0] has been selected in par. 8-05
End-of-Time-out
Do not reset
3
