How to Programme
Motor Set-up
The Quick Menu Motor Set-up guides through the needed
motor parameters.
2 2
No & Name
0-03 Regional
Settings
1-20 Motor
Powerr
1-22 Motor
Voltage
1-23 Motor
Frequency
1-24 Motor
Current
1-25 Motor
Nominal Speed
4-12 Motor
Speed Low
Limit [Hz]
4-14 Motor
Speed High
Limit [Hz]
3-41 Ramp 1
Ramp up Time
3-42 Ramp 1
Ramp Down
Time
1-73 Flying
Start
18
VLT HVAC Basic Drive Programming Guide
Range Default Function
[0] Interna- 0
tional
[1] US
0.12-110kW/ Size related Enter motor
0.16-150hp power from
nameplate data
50.0 - 1000.0V Size related Enter motor
voltage from
nameplate data
20.0 - 400.0Hz Size related Enter motor
frequency from
nameplate data
0.01 - Size related Enter motor
10000.00A current from
nameplate data
100.0 - 9999.0 Size related Enter motor
RPM nominal speed
from nameplate
data
0.0 - 400Hz 0.0Hz Enter the
minimum limit for
low speed
0.0 - 400HZ 65
0.05 - 3600.0 s Size related Ramp up time
from 0 to rated
1-23 Motor
Frequency
0.05 - 3600.0 s Size related Ramp down time
from rated
1-23 Motor
Frequency to 0
[0] Disabled 0 Select Enable to
[1] Enabled enable the
frequency
converter to catch
a spinning motor
MG.18.B1.02 - VLT
Changes Made
Changes Made lists all parameters changed since factory
setting. Only the changed parameters in current edit-setup
are listed in changes made.
If the parameter's value is changed back to factory setting's
value from another different value, the parameter will NOT
be listed in Changes Made.
1. Press [MENU] key to enter the Quick Menu until
indicator in display is placed above Quick Menu.
▲ ▼
2.
Press [ ] [
loop setup, motor setup or changes made, then
press [OK].
▲ ▼
3.
Press [ ] [
the Quick Menu.
4. Press [OK] to select a parameter.
▲ ▼
5.
Press [ ] [
setting.
6. Press [OK] to accept the change.
7. Press either [Back] twice to enter "Status", or press
[Menu] once to enter "Main Menu".

2.3.4 Main Menu

[Main Menu] is used for programming all parameters. The
Main Menu parameters can be accessed immediately unless
a password has been created via 0-60 Main Menu Password.
For the majority of VLT HVAC Basic Drive applications it is not
necessary to access the Main Menu parameters but instead
the Quick Menu provides the simplest and quickest access to
the typical required parameters.
The Main Menu accesses all parameters.
1. Press [MENU] key until indicator in display is placed
above "Main Menu".
▲ ▼
2.
Use [ ] [ ] to browse through the parameter
groups.
3. Press [OK] to select a parameter group.
▲ ▼
4.
Use [ ] [ ] to browse through the parameters in
the specific group.
5. Press [OK] to select the parameter.
▲ ▼
6.
Use [ ] [ ] to set/change the parameter value.
[BACK] is used to go one level back.
®
is a registered Danfoss trademark
] to select either FC101 wizard, closed
] to browse through the parameters in
] to change the value of a parameter
