Specifications
The specifications presented here depend on the conditions in individual
laboratories. Refer to the ACQUITY System Site Preparation Guide, or contact
®
the Waters
specifications.
Contents:
Topic
Physical specifications ..................................................................... 153
Environmental specifications .......................................................... 154
Electrical specifications ................................................................... 154
Input/output specifications.............................................................. 155
Performance specifications .............................................................. 155
Wetted materials of construction .................................................... 158

Physical specifications

The following table lists the physical specifications for the ISM.

Physical specifications:

Attribute
Height
Width (including
tubing guide)
Depth
Weight
Technical Service organization for additional information about
Specification
24.5 cm (9.6 inches)
37.7 cm (14.9 inches)
61.5 cm (24.2 inches)
24.9 kg (55.0 pounds)
