2 Preparing for Operation
Installing the waste tubing and vent tubing for the
degasser
To install the tubing:
Caution:
solvent, wear clean, chemical-resistant, powder-free gloves when
installing or removing the waste and degasser vent tubing.
1.
Wet the barbed drain fitting at the bottom of the ISM with methanol.
Caution:
to leak, restrain the drain cup when attaching or removing the
waste tubing.
2.
Hold the back of the drain cup, slide the waste tubing over the barbed
drain fitting, and route the tubing to a suitable waste container.
Drip tray
Barbed drain fitting
40
September 26, 2013, 715004208 Rev. A
To prevent contamination and possible contact with
To avoid distorting the drip tray or causing the drain cup
Drain cup
