Major components

The following diagram shows the major components of the ISM:
Power LED Run LED
On/off
switch
Primary
pump
Primary
check
valve
Seal-wash
waste tube
Low-
pressure
inlet filter
Drip tray
Location of Flow-splitter or
Post-column Addition kit
(optional)
ISM components:
Component
Accumulator pump
Location of pressure
transducer cable
connector (2)
Accumulator
Accumulator
pump
check valve
Location of sample
manager purge
solvent degasser
chamber (optional)
Description
Receives solvent from the primary pump and delivers
it to the system.
ISM mobile phase
degasser chamber
Vent valve
waste tube
Location of leak
sensor cable
connector
September 26, 2013, 715004208 Rev. A
Major components
Vent valve
Inline
22-μL filter
Seal wash
pump
Location of
solvent
selection
valve
(optional)
Location of
degasser
vent tubing
Leak sensor Drain fitting
reservoir (to waste)
