3 Maintenance Procedures
4. Remove the leak sensor from its reservoir, grasping it by its serrations,
and pull upward on it.
Serrations
5. Unpack the new leak sensor.
6. Align the leak sensor's T-bar with the slot in the side of the leak sensor
reservoir, and slide the leak sensor into place.
7. Connect the leak sensor connector to the front of the instrument.
8. Power-on the ISM.
9. In the Instrument console, select Isocratic Solvent Manager from the
system tree.
10. In the ISM information window, click Control > Reset ISM, to reset the
ISM.
86 September 26, 2013, 715004208 Rev. A
T-bar
Slot in leak
sensor reservoir
