2 Preparing for Operation
6.
Using the T10 TORX driver, tighten the captive screws on the restrictor
module to the extent possible.
7.
Install the degasser and label on the flow-splitter face plate assembly.
Secure the degasser and label to the face plate assembly with the screw
removed in
52
September 26, 2013, 715004208 Rev. A
Captive screws
step
4, using the T10 TORX driver to tighten the screw.
Screw securing
degasser and label
to face plate
