B Specifications
®
ACQUITY UPLC and Alliance
Item
Restrictor module reproducibility
For ACQUITY UPLC and Alliance flow-splitter kits, the split ratio and
Note:
detector offset time are dependent on all chromatographic conditions and on
the system configuration.
2
UPC ® Flow-splitter kit performance specifications:
Item
Flow rate
Pressure

Wetted materials of construction

ISM

The following table lists the wetted materials of construction for the ISM.

Wetted materials of construction:

Description
Wetted materials
158 September 26, 2013, 715004208 Rev. A
®
Flow-splitter kit performance specifications:
Specification
± 15.0% of split ratio
Note:
replacing an individual restrictor
module only.
Specification
Up to 4.0 mL/min
41,369 kPa (414 bar, 6000 psi)
Specification
302 stainless-steel; 316 stainless-steel; DLC;
fluoropolymer; fluoroelastomer; UHMWPE blend;
PEEK; PEEK with 30% carbon fiber fill; PPS; PPS
with 20% fluoropolymer fill; ruby; sapphire;
titanium alloy; zirconia
This specification applies to
