2 Preparing for Operation
Installation recommendations for ACQUITY ISM fittings: (Continued)
Fitting
Stainless-steel (gold-plated) fitting with
short flats and 2-piece stainless-steel
ferrule.
Stainless-steel (gold-plated) fitting with
short flats and 2-piece stainless-steel
ferrule.
32
September 26, 2013, 715004208 Rev. A
Short flats
2-piece ferrule
Short flats
2-piece ferrule
Recommended tightening
Finger-tight, plus 3/4-turn
using wrench
TP03375
Finger-tight, plus up to
1/6-turn using wrench
1/6-turn
TP03374
3/4-turn
