Replacing the restrictor module in the optional ACQUITY UPC
If you are replacing the restrictor module in the ACQUITY UPC
Note:
Triple Detection Flow-splitter kit, you must also disconnect the outlet 4
tubing from the restrictor module.
Inlet 3
2.
Using the T10 TORX driver, loosen the two captive screws on the
restrictor module, and then remove the module.
3.
Insert the new restrictor module into the flow-splitter assembly.
4.
Using the T10 TORX driver, tighten the captive screws on the restrictor
module to the extent possible.
5.
Reconnect inlet 3, outlet 2, and outlet 3 to the new restrictor module.
Outlet 2:
Outlet 3:
To Convergence
To QDa detector
Manager tee
source
Restrictor module
Captive screws
September 26, 2013, 715004208 Rev. A
2
Flow-splitter kit
2
89
