4.
Unscrew the cap nut on the low-pressure inlet filter assembly.
5.
Pull the cap nut off the tube to remove the low-pressure filter cartridge.
Tube
Low-pressure filter cartridge and cap nut:
Low-pressure
filter cartridge
Metal locking ring
Replacing the low-pressure filter cartridge
Cap nut
Low-pressure filter
cartridge
Cap nut
Cap nut
September 26, 2013, 715004208 Rev. A
Tube
93
