Waters ACQUITY Isocratic Solvent Manager Overview And Maintenance Manual page 21

Restrictor module 5: (Continued)
Make-up flow
Organic Composition
Methanol 10% organic
50% organic
Acetonitrile 10% organic
50% organic
Restrictor module 10:
Make-up flow
Organic Composition
Isopropanol 10% organic
50% organic
Methanol 10% organic
50% organic
Acetonitrile 10% organic
50% organic
Restrictor module 100:
Make-up flow
Organic Composition
Isopropanol 10% organic
50% organic
Methanol 10% organic
50% organic
Acetonitrile 10% organic
50% organic
Mobile phase concentration at
QDa detector
Minimum % Maximum %
5.5 27.2
5.1 25.1
5.6 28.2
5.8 29.3
Mobile phase concentration at
QDa detector
Minimum % Maximum %
2.4 13.7
1.7 9.2
2.5 14.1
2.3 13.0
2.6 14.5
2.6 15.1
Mobile phase concentration at
QDa detector
Minimum % Maximum %
0.2 1.5
0.1 1.0
0.2 1.6
0.2 1.4
0.2 1.6
0.2 1.7
September 26, 2013, 715004208 Rev. A
Major components
21
