2 Preparing for Operation
Installing the optional ACQUITY UPC
Flow-splitter kit
Required materials
•
Gloves: clean, powder-free, chemical-resistant
•
ACQUITY UPC
To install the optional ACQUITY UPC
1.
Disconnect the finger-tight fittings from the outlet and inlet of the
degasser.
2.
Using the T10 TORX driver, remove the five screws that secure the
blank face plate to the front face of the ISM chassis.
Blank face plate
56
September 26, 2013, 715004208 Rev. A
2
Triple-Detection Flow-splitter kit
2
Triple-Detection Flow-splitter kit:
Degasser
outlet
Screws securing
blank face plate
Screws securing
blank face plate
2
Triple-Detection
Degasser
inlet
