Specifications
These system specifications depend on the conditions in individual
laboratories. Refer to the ACQUITY UPLC I-Class (IVD) System Site
Preparation Guide (part number 715003724), or contact Waters
Technical Service for details.
For specifications on the mass spectrometer, see the Xevo TQ-S
Note:
IVD Mass Spectrometry System Operator's Overview and Maintenance
Guide.
Contents:
Topic

Physical specifications

Environmental specifications
The following table lists the environmental specifications for the
ACQUITY UPLC I-Class IVD system:
Wetted materials of construction
Physical specifications

Binary solvent manager

The following table lists the physical specifications for the ACQUITY UPLC
I-Class IVD BSM:
BSM physical specifications:
Attribute
Height
Width
Depth
Weight
Specification
22.9 cm (9.0 inches)
34.3 cm (13.5 inches)
66.0 cm (26.0 inches)
26.3 kg (58.0 pounds)
July 7, 2014, 715003736IVD Rev. C
Physical specifications
Page
61
63
63
67
61
