3.
Disconnect the vacuum tubing that is attached to the back of the
degassing chamber.
4.
Using the T10 TORX driver, remove the screw that secures the
degassing chamber and label to the front of the face plate, and then
remove them from the face plate.
5.
Install the triple-detection flow-splitter restrictor module on the
flow-splitter face plate assembly.
Installing the optional ACQUITY UPC
Location of
vacuum tubing
Screw securing
degasser and label
to face plate
September 26, 2013, 715004208 Rev. A
2
Flow-splitter kits
57
