4.
Using the T10 TORX driver, remove the screw that secures the
degassing chamber and label to the front of the face plate, and then
remove them from the face plate.
5.
Install the degasser and label on the flow-splitter face plate assembly.
Secure the degasser and label to the face plate assembly with the screw
removed in
step
Installing the optional ACQUITY UPLC or Alliance Flow-splitter kit
Screw securing
degasser and label
to face plate
4, using the T10 TORX driver to tighten the screw.
Screw securing
degasser and label
to face plate
September 26, 2013, 715004208 Rev. A
45
