Removing the primary head and replacing its seals

See the ACQUITY online Help to help determine whether you need to replace
the primary head seals.
Warning:
when you handle solvents, change tubing, or operate the ISM. Consult
the Material Safety Data Sheets regarding the solvents you use.
Caution:
powder-free gloves when removing and replacing the head seals.
Required materials
• Compressed air
• Gloves: clean, powder-free, chemical-resistant
• Methanol
• Plunger (recommended)
• Plunger seal and plunger-seal spacer
• Fluoropolymer O-ring
• Seal-wash seal
Required tools
• 1/4-inch, open-end wrench
• 5/16-inch, open-end wrench
• Plunger removal tool (recommended)
• Seal extraction tool
• Sharp tool
• T27 TORX driver (startup kit)
• Torque wrench

Removing the primary head and replacing its seals

To prevent injury, always observe Good Laboratory Practices
To prevent contamination, wear clean, chemical-resistant,
