2 Preparing for Operation
2.
Using the T10 TORX driver, remove the five screws that secure the
blank face plate to the front face of the ISM chassis.
Blank face plate
3.
Disconnect the vacuum tubing that is attached to the back of the
degassing chamber.
44
September 26, 2013, 715004208 Rev. A
Screws securing
blank face plate
Screws securing
blank face plate
Location of
vacuum tubing
