Danfoss VLT Refrigeration Drive FC 103 Programming Manual page 102

Parameter Description
13-40 Logic Rule Boolean 1
Array [6]
Option:
[19] Warning
3 3
[20] Alarm (trip)
[21] Alarm (trip lock)
[22] Comparator 0
[23] Comparator 1
[24] Comparator 2
[25] Comparator 3
[26] Logic rule 0
[27] Logic rule 1
[28] Logic rule 2
[29] Logic rule 3
[30] SL Time-out 0
[31] SL Time-out 1
[32] SL Time-out 2
[33] Digital input DI18
[34] Digital input DI19
[35] Digital input DI27
[36] Digital input DI29
[37] Digital input DI32
[38] Digital input DI33
[39] Start command
100
®
VLT Refrigeration Drive FC 103
Function:
See parameter group 5-3* Digital Outputs
for further description.
See parameter group 5-3* Digital Outputs
for further description.
See parameter group 5-3* Digital Outputs
for further description.
Use the result of comparator 0 in the
logic rule.
Use the result of comparator 1 in the
logic rule.
Use the result of comparator 2 in the
logic rule.
Use the result of comparator 3 in the
logic rule.
Use the result of logic rule 0 in the logic
rule.
Use the result of logic rule 1 in the logic
rule.
Use the result of logic rule 2 in the logic
rule.
Use the result of logic rule 3 in the logic
rule.
Use the result of timer 0 in the logic
rule.
Use the result of timer 1 in the logic
rule.
Use the result of timer 2 in the logic
rule.
Use the value of DI 18 in the logic rule
(High = true).
Use the value of DI 19 in the logic rule
(High = true).
Use the value of DI 27 in the logic rule
(High = true).
Use the value of DI 29 in the logic rule
(High = true).
Use the value of DI 32 in the logic rule
(High = true).
Use the value of DI 33 in the logic rule
(High = true).
This logic rule is true if the frequency
converter is started either via digital
input, fieldbus, or other.
Danfoss A/S © 05/2016 All rights reserved.
13-40 Logic Rule Boolean 1
Array [6]
Option: Function:
[40] Drive stopped This logic rule is true if the frequency
converter is stopped or coasted either
via digital input, fieldbus, or other.
[41] Reset Trip This logic rule is true if the frequency
converter is tripped (but not trip-locked)
and [Reset] is pressed.
[42] Auto Reset Trip This logic rule is true if the frequency
converter is tripped (but not trip-locked)
and an automatic reset is issued.
[43] OK Key This logic rule is true if [OK] is pressed.
[44] Reset Key This logic rule is true if [Reset] is
pressed.
[45] Left Key This logic rule is true if [◄] is pressed.
[46] Right Key This logic rule is true if [►] is pressed.
[47] Up Key
This logic rule is true if [
[48] Down Key
This logic rule is true if [
[50] Comparator 4 Use the result of comparator 4 in the
logic rule.
[51] Comparator 5 Use the result of comparator 5 in the
logic rule.
[60] Logic rule 4 Use the result of logic rule 4 in the logic
rule.
[61] Logic rule 5 Use the result of logic rule 5 in the logic
rule.
[70] SL Time-out 3 Use the result of timer 3 in the logic
rule.
[71] SL Time-out 4 Use the result of timer 4 in the logic
rule.
[72] SL Time-out 5 Use the result of timer 5 in the logic
rule.
[73] SL Time-out 6 Use the result of timer 6 in the logic
rule.
[74] SL Time-out 7 Use the result of timer 7 in the logic
rule.
[80] No Flow
[81] Dry Pump
[82] End of Curve
[83] Broken Belt
13-41 Logic Rule Operator 1
Array [6]
Option: Function:
Select the 1 st logical operator to use on the
boolean inputs from parameter 13-40 Logic Rule
Boolean 1 and parameter 13-42 Logic Rule
Boolean 2.
▲
] is pressed.
▼
] is pressed.
