Parameter Description
0-20 Display Line 1.1 Small
Option: Function:
[1653] Digi Pot View the contribution of the digital
Reference potentiometer to the actual reference
feedback.
[1654] Feedback 1 View the value of feedback 1. See also
[Unit] parameter group 20-0* FC Closed Loop.
[1655] Feedback 2 View the value of feedback 2. See also
[Unit] parameter group 20-0* FC Closed Loop.
[1656] Feedback 3 View the value of feedback 3. See also
[Unit] parameter group 20-0* FC Closed Loop.
[1660] Digital Input Shows the status of the digital inputs.
Signal low = 0; Signal high = 1.
Regarding order, see
parameter 16-60 Digital Input. Bit 0 is at
the extreme right.
[1661] Terminal 53 Setting of input terminal 53. Current =
Switch Setting 0; Voltage = 1.
[1662] Analog Input 53 Actual value at input 53 either as a
reference or protection value.
[1663] Terminal 54 Setting of input terminal 54. Current =
Switch Setting 0; Voltage = 1.
[1664] Analog Input 54 Actual value at input 54 either as
reference or protection value.
[1665] Analog Output Actual value at output 42 in mA. Use
42 [mA] parameter 6-50 Terminal 42 Output to
select the variable to be represented by
output 42.
[1666] Digital Output Binary value of all digital outputs.
[bin]
[1667] Pulse Input #29 Actual value of the frequency applied
[Hz] at terminal 29 as a pulse input.
[1668] Pulse Input #33 Actual value of the frequency applied
[Hz] at terminal 33 as a pulse input.
[1669] Pulse Output Actual value of pulses applied to
#27 [Hz] terminal 27 in digital output mode.
[1670] Pulse Output Actual value of pulses applied to
#29 [Hz] terminal 29 in digital output mode.
[1671] Relay Output View the setting of all relays.
[bin]
[1672] Counter A View the present value of counter A.
[1673] Counter B View the present value of counter B.
[1675] Analog In Actual value of the signal on input
X30/11 X30/11 (general purpose I/O card.
Optional).
[1676] Analog In Actual value of the signal on input
X30/12 X30/12 (general purpose I/O card.
Optional).
[1677] Analog Out Actual value at output X30/8 (general
X30/8 [mA] purpose I/O card. Optional). Use
MG16H202
Programming Guide
0-20 Display Line 1.1 Small
Option:
[1678] Analog Out
[1679] Analog Out
[1680] Fieldbus CTW 1
[1682] Fieldbus REF 1
[1684] Comm. Option
[1685] FC Port CTW 1
[1686] FC Port REF 1
[1690] Alarm Word
[1691] Alarm Word 2
[1692] Warning Word
[1693] Warning Word 2 One or more warnings in a hex code
[1694] Ext. Status Word One or more status conditions in a hex
[1695] Ext. Status Word
[1696] Maintenance
[1699] Ext. Status Word
[1830] Analog Input
[1831] Analog Input
[1832] Analog Input
[1833] Analog Out
Danfoss A/S © 05/2016 All rights reserved.
Function:
parameter 6-60 Terminal X30/8 Output to
select the variable to be shown.
X45/1 [mA]
X45/3 [mA]
Control word (CTW) received from the
bus master.
Main reference value sent with control
word via the serial communications
network, for example from the BMS,
PLC, or other master controller.
Extended fieldbus communication
STW option status word.
Control word (CTW) received from the
bus master.
Status word (STW) sent to the bus
master.
One or more alarms in a hex code
(used for serial communications).
One or more alarms in a hex code
(used for serial communications).
One or more warnings in a hex code
(used for serial communications).
(used for serial communications).
code (used for serial communications).
One or more status conditions in a hex
2 code (used for serial communications).
The bits reflect the status for the
Word programmed preventive maintenance
events in parameter group 23-1*
Maintenance.
3
Shows the value of the signal applied
X42/1 to terminal X42/1 on the analog I/O
card.
Shows the value of the signal applied
X42/3 to terminal X42/3 on the analog I/O
card.
Shows the value of the signal applied
X42/5 to terminal X42/5 on the analog I/O
card.
Shows the value of the signal applied
X42/7 [V] to terminal X42/7 on the analog I/O
card.
3 3
