Introduction
PDS Power drive system: A CDM and a motor
PELV Protective extra low voltage
P Frequency converter nominal output power as
m
high overload (HO)
P Nominal motor power
M,N
PM motor Permanent magnet motor
Process PID PID (proportional integrated differential) regulator
that maintains the speed, pressure, temperature,
and so on
R Nominal resistor value that ensures a brake power
br,nom
on the motor shaft of 150/160% for 1 minute
RCD Residual current device
Regen Regenerative terminals
R Minimum permissible brake resistor value by
min

frequency converter

RMS Root mean square
RPM Revolutions per minute
R Recommended brake resistor resistance of
rec
Danfoss brake resistors
s Second
SCCR Short circuit current rating
SFAVM Stator flux-oriented asynchronous vector
modulation
STW Status word
SMPS Switch mode power supply
THD Total harmonic distortion
T Torque limit
LIM
TTL TTL encoder (5 V) pulses - transistor transistor
logic
U Nominal motor voltage
M,N
UL Underwriters Laboratories (US organization for the
safety certification)
V Volts
VT Variable torque
Voltage vector control plus
VVC +
Table 1.2 Abbreviations
Conventions
Numbered lists indicate procedures.
Bullet lists indicate other information and description of
illustrations.
Italicized text indicates:
•
Cross-reference.
•
Link.
•
Footnote.
•
Parameter name, parameter group name,
parameter option.
All dimensions in drawings are in mm (in).
* Indicates a default setting of a parameter.
•
®
VLT Refrigeration Drive FC 103 Operating
Instructions provides information on mechanical
MG16H202
Programming Guide
•
•
•
•

1.1 Definitions

1.1.1 Frequency Converter
I
VLT,MAX
Maximum output current.
I
VLT,N
Rated output current supplied by the frequency converter.
U
VLT,MAX
Maximum output voltage.

1.1.2 Input

Control command
Start and stop the connected motor with LCP and digital
inputs.
Functions are divided into 2 groups.
Functions in group 1 have higher priority than functions in
group 2.
Group 1
Group 2
Table 1.3 Function Groups

1.1.3 Motor

Motor running
Torque generated on output shaft and speed from 0 RPM
to maximum speed on motor.
f
JOG
Motor frequency when the jog function is activated (via
digital terminals).
f
M
Motor frequency.
f
MAX
Maximum motor frequency.
Danfoss A/S © 05/2016 All rights reserved.
and electrical installation of the frequency
converter.
®
VLT Refrigeration Drive FC 103 Design Guide holds
all technical information about the frequency
converter, customer design, and applications.
®
VLT Refrigeration Drive FC 103 Programming Guide
provides information on how to program and
includes complete parameter descriptions.
MCT 10 Set-up Software Operating Instructions
enables the user to configure the frequency
converter from a Windows™-based PC
environment.
® ®
VLT HVAC Drive FC 102/VLT AQUA Drive FC 202
Metasys N2, Operating Instructions.
Reset, coast stop, reset and coast stop, quick stop,
DC brake, stop, the [OFF] key.
Start, pulse start, reversing, start reversing, jog,
freeze output.
1 1
5
