Parameter Description
6-62 Terminal X30/8 Max. Scale
Range:
Function:
100
[0 -
Scales the maximum output of the selected
%
200 %
analog signal on terminal X30/8. Scale the value
*
]
to the required maximum value of the current
signal output. Scale the output to give a lower
current than 20 mA at full scale, or 20 mA at an
output below 100% of the maximum signal value.
If 20 mA is the required output current at a value
between 0–100% of the full-scale output,
program the percentage value in the parameter,
that is 50%=20 mA. If a current 4–20 mA is
required at maximum output (100%), calculate
the percentage value as follows:
20 mA/desired maximum current  ×  100 %
20 mA
i . e .  10 mA:
  ×  100 % = 200 %
10 mA
6-63 Terminal X30/8 Output Bus Control
Range:
Function:
0 %
[0 - 100 %] Contains the value to apply to the output
*
terminal when it is configured as bus-
controlled.
6-64 Terminal X30/8 Output Timeout Preset
Range:
Function:
0 %
[0 - 100 %] Contains the value to apply to the output
*
terminal, when it is configured as bus-
controlled timeout and timeout is detected.
6-70 Terminal X45/1 Output
Select the output of terminal X45/1 of VLT
MCB 113.
Option:
[0]
No operation
*
[100]
Output frequency
[101]
Reference
[102]
Feedback
[103]
Motor Current
[104]
Torque rel to limit
[105]
Torq relate to rated
[106]
Power
[107]
Speed
[108]
Torque
[109]
Max Out Freq
[113]
Ext. Closed Loop 1
[114]
Ext. Closed Loop 2
[115]
Ext. Closed Loop 3
[121]
Air pres. to Flow
[122]
Air pres. to Flow 4-20mA
[130]
Output freq. 4-20mA
[131]
Reference 4-20mA
[132]
Feedback 4-20mA
[133]
Motor cur. 4-20mA
[134]
Torq.% lim 4-20 mA
MG16H202
Programming Guide
6-70 Terminal X45/1 Output
Select the output of terminal X45/1 of VLT
MCB 113.
Option:
[135]
[136]
[137]
[138]
[139]
[140]
[141]
[142]
[143]
[144]
[145]
[150]
[184]
[185]
6-71 Terminal X45/1 Min. Scale
Enter the minimum scaling value of output of the analog signal
on terminal X45/1.
Range:
0 %
6-72 Terminal X45/1 Max. Scale
Enter the maximum scaling value of output of the analog signal
on terminal X45/1.
Range:
100 %
®
Extended Relay Card
6-73 Terminal X45/1 Bus Control
Function:
Enter the output value for terminal X45/1 when the fieldbus
controls the terminal.
Range:
0 %
6-74 Terminal X45/1 Output Timeout Preset
Enter the output value for terminal X45/1 when the bus control
timeout for the terminal is detected.
Range:
0 %
6-80 Terminal X45/3 Output
Select the output of terminal X45/3 of VLT
MCB 113.
Option:
[0]
[100]
[101]
[102]
[103]
[104]
[105]
Danfoss A/S © 05/2016 All rights reserved.
Torq.% nom 4-20mA
Power 4-20mA
Speed 4-20mA
Torque 4-20mA
Bus ctrl.
Bus ctrl. 4-20 mA
Bus ctrl t.o.
Bus ctrl t.o. 4-20mA
Ext. CL 1 4-20mA
Ext. CL 2 4-20mA
Ext. CL 3 4-20mA
Max Out Fr 4-20 mA
Mirror AI53 mA
Mirror AI54 mA
[0 - 200 %]
*
[0 - 200 %]
*
[0 - 100 %]
*
[0 - 100 %]
*
No operation
*
Output frequency
Reference
Feedback
Motor Current
Torque rel to limit
Torq relate to rated
®
Extended Relay Card
Function:
3
Function:
Function:
Function:
Function:
®
Extended Relay Card
Function:
85
3
