Parameter Description
16-72 Counter A
Range:
0 [-2147483648
*
- 2147483647]
3 3
16-73 Counter B
Range:
0 [-2147483648
*
- 2147483647]
16-75 Analog In X30/11
Range:
0 [-20 - 20] View the actual value at input X30/11 of VLT
*
16-76 Analog In X30/12
Range:
0 [-20 - 20] View the actual value at input X30/12 of VLT
*
16-77 Analog Out X30/8 [mA]
Range:
0 [0 - 30]
*
16-78 Analog Out X45/1 [mA]
Range:
0 [0 - 30] Shows the actual output value at terminal X45/1.
*
16-79 Analog Out X45/3 [mA]
Range:
0 [0 - 30] Shows the actual output value at terminal X45/3.
*
122
Function:
View the present value of counter A.
Counters are useful as comparator operands,
see parameter 13-10 Comparator Operand.
Reset or change the value either via digital
inputs (parameter group 5-1* Digital Inputs)
or by using an SLC action
(parameter 13-52 SL Controller Action).
Function:
View the present value of counter B.
Counters are useful as comparator operands
(parameter 13-10 Comparator Operand).
Reset or change the value either via digital
inputs (parameter group 5-1* Digital Inputs)
or by using an SLC action
(parameter 13-52 SL Controller Action).
Function:
General Purpose I/O MCB 101.
Function:
General Purpose I/O MCB 101.
Function:
View the actual value at input X30/8 in mA.
Function:
The value shown reflects the selection in
parameter 6-70 Terminal X45/1 Output.
Function:
The value shown reflects the selection in
parameter 6-80 Terminal X45/3 Output.
Danfoss A/S © 05/2016 All rights reserved.
®
VLT Refrigeration Drive FC 103
3.14.6 16-8* Fieldbus & FC Port
Parameters for reporting the bus references and control
words.
16-80 Fieldbus CTW 1
Range:
0 [0 -
*
65535]
16-82 Fieldbus REF 1
Range:
0 [-200 -
*
200]
®
16-84 Comm. Option STW
Range:
0 [0 - 65535] Shows the status word of the extended fieldbus
*
®
16-85 FC Port CTW 1
Range:
0 [0 - 65535] View the 2-byte control word (CTW) received
*
16-86 FC Port REF 1
Range:
0 [-200 -
*
200]
Function:
View the 2-byte control word (CTW) received
from the fieldbus master. Interpretation of the
control word depends on the fieldbus option
installed and the control word profile selected in
parameter 8-10 Control Profile.
For more information, refer to the relevant
fieldbus manual.
Function:
View the 2-byte word sent with the control
word from the fieldbus master to set the
reference value.
For more information, refer to the relevant
fieldbus manual.
Function:
communication option.
For more information, refer to the relevant
fieldbus manual.
Function:
from the fieldbus master. Interpretation of the
control word depends on the fieldbus option
installed and the control word profile selected
in parameter 8-10 Control Profile.
Function:
View the 2-byte status word (STW) sent to the
fieldbus master. Interpretation of the status word
depends on the fieldbus option installed and the
control word profile selected in
parameter 8-10 Control Profile.
