Parameter Lists

4.1.5 3-** Reference/Ramps

Param- Parameter description
eter #
3-0* Reference Limits
3-02 Minimum Reference
3-03 Maximum Reference
3-04 Reference Function
4 4
3-1* References
3-10 Preset Reference
3-11 Jog Speed [Hz]
3-13 Reference Site
3-14 Preset Relative Reference
3-15 Reference 1 Source
3-16 Reference 2 Source
3-17 Reference 3 Source
3-19 Jog Speed [RPM]
3-4* Ramp 1
3-41 Ramp 1 Ramp Up Time
3-42 Ramp 1 Ramp Down Time
3-5* Ramp 2
3-51 Ramp 2 Ramp Up Time
3-52 Ramp 2 Ramp Down Time
3-8* Other Ramps
3-80 Jog Ramp Time
3-81 Quick Stop Ramp Time
3-82 Starting Ramp Up Time
3-9* Digital Pot.Meter
3-90 Step Size
3-91 Ramp Time
3-92 Power Restore
3-93 Maximum Limit
3-94 Minimum Limit
3-95 Ramp Delay
200
®
VLT Refrigeration Drive FC 103
Default value 4 set-up
ExpressionLimit All set-ups
ExpressionLimit All set-ups
[0] Sum All set-ups
0 % All set-ups
ExpressionLimit All set-ups
[0] Linked to
Hand / Auto All set-ups
0 % All set-ups
[1] Analog Input 53 All set-ups
[20] Digital
pot.meter All set-ups
[0] No function All set-ups
ExpressionLimit All set-ups
ExpressionLimit All set-ups
ExpressionLimit All set-ups
ExpressionLimit All set-ups
ExpressionLimit All set-ups
ExpressionLimit All set-ups
ExpressionLimit 2 set-ups
ExpressionLimit 2 set-ups
0.10 % All set-ups
1 s All set-ups
[0] Off All set-ups
100 % All set-ups
0 % All set-ups
1 N/A All set-ups
Danfoss A/S © 05/2016 All rights reserved.
Change during Conversion
operation index
TRUE -3
TRUE -3
TRUE -
TRUE -2
TRUE -1
TRUE -
TRUE -2
TRUE -
TRUE -
TRUE -
TRUE 67
TRUE -2
TRUE -2
TRUE -2
TRUE -2
TRUE -2
TRUE -2
TRUE -2
TRUE -2
TRUE -2
TRUE -
TRUE 0
TRUE 0
TRUE -3
Type
Int32
Int32
Uint8
Int16
Uint16
Uint8
Int32
Uint8
Uint8
Uint8
Uint16
Uint32
Uint32
Uint32
Uint32
Uint32
Uint32
Uint32
Uint16
Uint32
Uint8
Int16
Int16
TimD
