Parameter Lists
Param- Parameter description
eter #
14-8* Options
14-80 Option Supplied by External 24VDC
14-89 Option Detection
14-9* Fault Settings
14-90 Fault Level

4.1.13 15-** FC Information

Param- Parameter description
eter #
15-0* Operating Data
15-00 Operating hours
15-01 Running Hours
15-02 kWh Counter
15-03 Power Up's
15-04 Over Temp's
15-05 Over Volt's
15-06 Reset kWh Counter
15-07 Reset Running Hours Counter
15-08 Number of Starts
15-1* Data Log Settings
15-10 Logging Source
15-11 Logging Interval
15-12 Trigger Event
15-13 Logging Mode
15-14 Samples Before Trigger
15-2* Historic Log
15-20 Historic Log: Event
15-21 Historic Log: Value
15-22 Historic Log: Time
15-23 Historic log: Date and Time
15-3* Alarm Log
15-30 Alarm Log: Error Code
15-31 Alarm Log: Value
15-32 Alarm Log: Time
15-33 Alarm Log: Date and Time
15-34 Alarm Log: Status
15-35 Alarm Log: Alarm Text
15-4* Drive Identification
15-40 FC Type
15-41 Power Section
15-42 Voltage
15-43 Software Version
15-44 Ordered Typecode String
15-45 Actual Typecode String
15-46 Frequency Converter Ordering No
15-47 Power Card Ordering No
15-48 LCP Id No
15-49 SW ID Control Card
15-50 SW ID Power Card
15-51 Frequency Converter Serial Number
MG16H202
Programming Guide
Default value 4 set-up
[1] Yes 2 set-ups
[0] Protect Option
Config. 1 set-up
ExpressionLimit 1 set-up
Default value 4 set-up
0 h All set-ups
0 h All set-ups
0 kWh All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
[0] Do not reset All set-ups
[0] Do not reset All set-ups
0 N/A All set-ups
0 2 set-ups
ExpressionLimit 2 set-ups
[0] False 1 set-up
[0] Log always 2 set-ups
50 N/A 2 set-ups
0 N/A All set-ups
0 N/A All set-ups
0 ms All set-ups
ExpressionLimit All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 s All set-ups
ExpressionLimit All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
