Parameter Description
8a
8b
8c
8d
3 3
9. Switch back with [Auto On] or [Off].
22-30 No-Flow Power
Range:
0 kW [0 - 1000
*
kW]
22-31 Power Correction Factor
Range:
100 % [1 -
400 %]
*
22-32 Low Speed [RPM]
Range:
Size [ 0 - par.
related 22-36
*
RPM]
22-33 Low Speed [Hz]
Range:
Size [ 0 - par.
related 22-37 Hz]
*
22-34 Low Speed Power [kW]
Range:
Size [ 0 -
related 5.50
*
kW]
22-35 Low Speed Power [HP]
Range:
Size [ 0 -
related 7.50 hp]
*
150
VLT
Parameter 22-34 Low Speed Power [kW].
Parameter 22-35 Low Speed Power [HP].
Parameter 22-38 High Speed Power [kW].
Parameter 22-39 High Speed Power [HP].
Function:
Readout of calculated no-flow power at
actual speed. If power drops to the display
value, the frequency converter considers
the condition as a no-flow situation.
Function:
Make corrections to the calculated power in
parameter 22-30 No-Flow Power.
If no-flow is detected when it should not be
detected, decrease the setting. However, if no-
flow is not detected when it should be
detected, increase the setting to above 100%.
Function:
To be used if parameter 0-02 Motor Speed
Unit is set to [0] RPM (parameter not
visible if [1] Hz is selected).
Set used speed for the 50% level.
This function is used for storing values
necessary for tuning no-flow detection.
Function:
To be used if parameter 0-02 Motor Speed
Unit is set for [1] Hz (parameter not visible
if [0] RPM is selected).
Set used speed for the 50% level.
The function is used for storing values
necessary for tuning no-flow detection.
Function:
To be used if parameter 0-03 Regional
Settings is set for [0] International
(parameter not visible if [1] North America is
selected).
Set power consumption at 50% speed level.
This function is used for storing values
necessary for tuning no-flow detection.
Function:
To be used if parameter 0-03 Regional
Settings is set for [1] North America
Danfoss A/S © 05/2016 All rights reserved.
®
Refrigeration Drive FC 103
22-35 Low Speed Power [HP]
Range:
22-36 High Speed [RPM]
Range:
Size
related
*
22-37 High Speed [Hz]
Range:
Size
related
*
22-38 High Speed Power [kW]
Range:
Size
related
*
22-39 High Speed Power [HP]
Range:
Size
related
*
3.18.4 22-4* Sleep Mode
If the load on the system allows for stop of the motor and
the load is monitored, the motor can be stopped by
activating the sleep mode function. This is not a normal
stop command, but ramps the motor down to 0 RPM and
stops energising the motor. When in sleep mode, certain
Function:
(parameter not visible if [0] International is
selected).
Set power consumption at 50% speed level.
This function is used for storing values
necessary for tuning no-flow detection.
Function:
[ 0 - To be used if parameter 0-02 Motor Speed
par. 4-13 Unit is set for [0] RPM (parameter not
RPM] visible if [1] Hz is selected).
Set used speed for the 85% level.
The function is used for storing values
necessary for tuning no-flow detection.
Function:
[ 0 - To be used if parameter 0-02 Motor Speed
par. 4-14 Unit is set for [1] Hz (parameter not visible
Hz] if [0] RPM is selected).
Set used speed for the 85% level.
The function is used for storing values
necessary for tuning no-flow detection.
Function:
[ 0 - To be used, if parameter 0-03 Regional
5.50 Settings is set for [0] International
kW] (parameter not visible if [1] North America is
selected).
Set power consumption at 85% speed level.
This function is used for storing values
necessary for tuning no-flow detection.
Function:
[ 0 - To be used if parameter 0-03 Regional
7.50 hp] Settings is set for [1] North America
(parameter not visible if [0] International is
selected).
Set power consumption at 85% speed level.
This function is used for storing values
necessary for tuning no-flow detection.
