Parameter Description
13-02 Stop Event
Option: Function:
[37] Digital input DI32 Use the value of DI 32 in the logic rule
(High = true).
[38] Digital input DI33 Use the value of DI 33 in the logic rule
(High = true).
[39] Start command This event is true if the frequency
converter is started (either via digital
input, fieldbus or other).
[40] Drive stopped This event is true if the frequency
converter is stopped or coasted (either
via digital input, fieldbus or other).
[41] Reset Trip This event is true if the frequency
converter is tripped (but not trip-locked)
and [Reset] is pressed.
[42] Auto Reset Trip This event is true if the frequency
converter is tripped (but not trip-locked)
and an automatic reset is issued.
[43] OK Key This event is true if [OK] is pressed.
[44] Reset Key This event is true if [Reset] is pressed.
[45] Left Key This event is true if [◄] is pressed.
[46] Right Key This event is true if [►] is pressed.
[47] Up Key
This event is true if [
[48] Down Key
This event is true if [
[50] Comparator 4 Use the result of comparator 4 in the
logic rule.
[51] Comparator 5 Use the result of comparator 5 in the
logic rule.
[60] Logic rule 4 Use the result of logic rule 4 in the logic
rule.
[61] Logic rule 5 Use the result of logic rule 5 in the logic
rule.
[70] SL Time-out 3 Use the result of timer 3 in the logic
rule.
[71] SL Time-out 4 Use the result of timer 4 in the logic
rule.
[72] SL Time-out 5 Use the result of timer 5 in the logic
rule.
[73] SL Time-out 6 Use the result of timer 6 in the logic
rule.
[74] SL Time-out 7 Use the result of timer 7 in the logic
rule.
[80] No Flow
[81] Dry Pump
[82] End of Curve
[83] Broken Belt
MG16H202
Programming Guide
13-03 Reset SLC
Option:
[0]
*
[1]
3.11.3 13-1* Comparators
13-10 Comparator Operand
Array [5]
Option:
[0]
[1]
[2]
[3]
[4]
[5]
[6]
[7]
[8]
▲ [9]
] is pressed.
[10]
▼
] is pressed.
[11]
[12]
[13]
[14]
[15]
[17]
[18]
[19]
[20]
[21]
[22]
[23]
[29]
[30]
[31]
[40]
[41]
[42]
[50]
[51]
[52]
[53]
[54]
[55]
[56]
[60]
[61]
[62]
Danfoss A/S © 05/2016 All rights reserved.
Function:
Do not reset Retains programmed settings in parameter
SLC group 13-** Smart Logic.
Reset SLC Resets all parameters in parameter group
13-** Smart Logic to default settings.
Function:
Select the variable to be
monitored by the comparator.
DISABLED
Reference %
Feedback %
Motor speed
Motor Current
Motor torque
Motor power
Motor voltage
DC-link voltage
Motor Thermal
Drive thermal
Heat sink temp.
Analog input AI53
Analog input AI54
Analog input AIFB10
Analog input AIS24V
Analog input AICCT
Pulse input FI29
Pulse input FI33
Alarm number
Warning number
Analog input x30 11
Analog input x30 12
Number Of Pump Running
Counter A
Counter B
Analog input x42/1
Analog input x42/3
Analog input x42/5
FALSE
TRUE
Control ready
Drive ready
Running
Reversing
In range
On reference
Below reference, low
Above ref, high
