Parameter Description
26-54 Terminal X42/9 Timeout Preset
Range:
0 %
[0 -
*
100 %]
3
3
3.21.7 26-6* Analog Input X42/11
26-60 Terminal X42/11 Output
Option:
[0]
No operation
*
[100] Output
frequency
[101] Reference
[102] Feedback
[103] Motor Current
[104] Torque rel to
limit
[105] Torq relate to
rated
[106] Power
[107] Speed
[108] Torque
[109] Max Out Freq
[113] Ext. Closed
Loop 1
[114] Ext. Closed
Loop 2
[115] Ext. Closed
Loop 3
[121] Air pres. to Flow
[139] Bus ctrl.
[141] Bus ctrl t.o.
26-61 Terminal X42/11 Min. Scale
For more information, see parameter 6-51 Terminal 42 Output Min
Scale.
Range:
0 %
[0 -
*
200 %]
186
VLT
Function:
Holds the preset level of terminal X42/9.
If a fieldbus and a timeout function are
selected in parameter 26-60 Terminal X42/11
Output, the output presets to this level.
Function:
Set the function of terminal X42/11.
0–100 Hz, (0–10 V).
Minimum reference–maximum reference,
(0–10 V).
-200% to +200% of
parameter 3-03 Maximum Reference, (0–10
V).
0–inverter maximum current
(parameter 16-37 Inv. Max. Current), (0–10
V).
0–torque limit (parameter 4-16 Torque
Limit Motor Mode), (0–10 V).
0–motor rated torque, (0–0 V).
0–motor rated power, (0–10 V).
0–speed high limit (parameter 4-13 Motor
Speed High Limit [RPM] and
parameter 4-14 Motor Speed High Limit
[Hz]), (0–10 V).
0–100%, (0–10 V).
0–100%, (0–10 V).
0–100%, (0–10 V).
0–100%, (0–10 V).
0–100%, (0–10 V).
Function:
Scale the minimum output of the selected
analog signal at terminal X42/11 as a
percentage of the maximum signal level. For
Danfoss A/S © 05/2016 All rights reserved.
®
Refrigeration Drive FC 103
26-61 Terminal X42/11 Min. Scale
For more information, see parameter 6-51 Terminal 42 Output Min
Scale.
Range:
26-62 Terminal X42/11 Max. Scale
See Illustration 3.31.
Range:
100
[0 -
%
200 %]
*
26-63 Terminal X42/11 Bus Control
Range:
0 %
[0 - 100 %] Holds the level of terminal X42/11 if
*
26-64 Terminal X42/11 Timeout Preset
Range:
0 %
[0 - 100 %] Holds the preset level of terminal X42/11.
*
Function:
example, if 0 V is required at 25% of the
maximum output value, program 25%. Scaling
values up to 100% can never be higher than
the corresponding setting in
parameter 26-62 Terminal X42/11 Max. Scale.
Function:
Scale the maximum output of the selected
analog signal at terminal X42/9. Set the value to
the maximum value of the voltage signal output.
Scale the output to give a voltage lower than 10
V at full scale; or 10 V at an output below 100%
of the maximum signal value. For example, if 10
V is the required output current at a value
between 0–100% of the full-scale output,
program the percentage value in the parameter,
that is, 50%=10 V. If a voltage 0–10 V is required
at maximum output, calculate the percentage as
follows:
10V
x100 %
desired maximum voltage
that is
10V
5V :
x100 % = 200 %
5V
Function:
controlled by bus.
Function:
If a fieldbus and a timeout function are
selected, the output presets to this level.
MG16H202
