Parameter Description
6-80 Terminal X45/3 Output
Select the output of terminal X45/3 of VLT
MCB 113.
Option:
[106]
3 3
[107]
[108]
[109]
[113]
[114]
[115]
[121]
[122]
[130]
[131]
[132]
[133]
[134]
[135]
[136]
[137]
[138]
[139]
[140]
[141]
[142]
[143]
[144]
[145]
[150]
[184]
[185]
6-81 Terminal X45/3 Min. Scale
Enter the minimum scaling value of output of the analog signal
on terminal X45/3.
Range:
0 %
*
6-82 Terminal X45/3 Max. Scale
Enter the maximum scaling value of output of the analog signal
on terminal X45/3.
Range:
100 %
*
6-83 Terminal X45/3 Bus Control
Enter the output value for terminal X45/3 when the fieldbus
controls the terminal.
Range:
0 %
*
86
®
Extended Relay Card
Power
Speed
Torque
Max Out Freq
Ext. Closed Loop 1
Ext. Closed Loop 2
Ext. Closed Loop 3
Air pres. to Flow
Air pres. to Flow 4-20mA
Output freq. 4-20mA
Reference 4-20mA
Feedback 4-20mA
Motor cur. 4-20mA
Torq.% lim 4-20 mA
Torq.% nom 4-20mA
Power 4-20mA
Speed 4-20mA
Torque 4-20mA
Bus ctrl.
Bus ctrl. 4-20 mA
Bus ctrl t.o.
Bus ctrl t.o. 4-20mA
Ext. CL 1 4-20mA
Ext. CL 2 4-20mA
Ext. CL 3 4-20mA
Max Out Fr 4-20 mA
Mirror AI53 mA
Mirror AI54 mA
Function:
[0 - 200 %]
Function:
[0 - 200 %]
Function:
[0 - 100 %]
Danfoss A/S © 05/2016 All rights reserved.
®
VLT Refrigeration Drive FC 103
6-84 Terminal X45/3 Output Timeout Preset
Enter the output value for terminal X45/3 when the bus control
timeout for the terminal is detected.
Range:
Function:
0 %
*
Function:
[0 - 100 %]
