Parameter Lists
Param- Parameter description
eter #
15-53 Power Card Serial Number
15-6* Option Ident
15-60 Option Mounted
15-61 Option SW Version
15-62 Option Ordering No
15-63 Option Serial No
4 4
15-70 Option in Slot A
15-71 Slot A Option SW Version
15-72 Option in Slot B
15-73 Slot B Option SW Version
15-74 Option in Slot C0/E0
15-75 Slot C0/E0 Option SW Version
15-76 Option in Slot C1/E1
15-77 Slot C1/E1 Option SW Version
15-8* Operating Data II
15-80 Fan Running Hours
15-81 Preset Fan Running Hours
15-9* Parameter Info
15-92 Defined Parameters
15-93 Modified Parameters
15-99 Parameter Metadata

4.1.14 16-** Data Readouts

Param- Parameter description
eter #
16-0* General Status
16-00 Control Word
16-01 Reference [Unit]
16-02 Reference [%]
16-03 Status Word
16-05 Main Actual Value [%]
16-09 Custom Readout
16-1* Motor Status
16-10 Power [kW]
16-11 Power [hp]
16-12 Motor Voltage
16-13 Frequency
16-14 Motor current
16-15 Frequency [%]
16-16 Torque [Nm]
16-17 Speed [RPM]
16-18 Motor Thermal
16-22 Torque [%]
16-24 Calibrated Stator Resistance
16-3* Drive Status
16-30 DC Link Voltage
16-31 System Temp.
16-32 Brake Energy /s
16-33 Brake Energy /2 min
208
®
VLT Refrigeration Drive FC 103
Default value 4 set-up
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 h All set-ups
0 h All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
Default value 4 set-up
0 N/A All set-ups
0 ReferenceFeed-
backUnit All set-ups
0 % All set-ups
0 N/A All set-ups
0 % All set-ups
0 CustomRea-
doutUnit All set-ups
0 kW All set-ups
0 hp All set-ups
0 V All set-ups
0 Hz All set-ups
0 A All set-ups
0 % All set-ups
0 Nm All set-ups
0 RPM All set-ups
0 % All set-ups
0 % All set-ups
0.0000 Ohm All set-ups
0 V All set-ups
0 °C All set-ups
0 kW All set-ups
0 kW All set-ups
Danfoss A/S © 05/2016 All rights reserved.
Change during Conversion
operation index
FALSE 0
FALSE 0
FALSE 0
FALSE 0
FALSE 0
FALSE 0
FALSE 0
FALSE 0
FALSE 0
FALSE 0
FALSE 0
FALSE 0
FALSE 0
TRUE 74
TRUE 74
FALSE 0
FALSE 0
FALSE 0
Change during Conversion
operation index
FALSE 0
FALSE -3
FALSE -1
FALSE 0
FALSE -2
FALSE -2
FALSE 1
FALSE -2
FALSE -1
FALSE -1
FALSE -2
FALSE -2
FALSE -1
FALSE 67
FALSE 0
FALSE 0
TRUE -4
FALSE 0
TRUE 100
FALSE 0
FALSE 0
Type
VisStr[19]
VisStr[30]
VisStr[20]
VisStr[8]
VisStr[18]
VisStr[30]
VisStr[20]
VisStr[30]
VisStr[20]
VisStr[30]
VisStr[20]
VisStr[30]
VisStr[20]
Uint32
Uint32
Uint16
Uint16
Uint16
Type
V2
Int32
Int16
V2
N2
Int32
Int32
Int32
Uint16
Uint16
Int32
N2
Int32
Int32
Uint8
Int16
Uint32
Uint16
Int8
Uint32
Uint32
